Product Details
＋
West Penn Wire 4245 24 AWG CAT5e UTP Fire Data Control Cable 1000FT (9 Colors)
West Penn Wire 4245 Category 5E Intercom Network Cable, non-plenum, featuring 24 AWG Solid bare copper conductors, 4 Pair, Polyolefin insulation, and overall PVC jacket.
West Penn Wire 4245 24 AWG CAT5e UTP Fire Data Control Cable 1000FT (9 Colors)
| Applications |
Indoor for:
- Category 5E Applications
- Ethernet
- IP Cameras
- Digital Integration
- And more....
| Ratings |
- NEC Type CMR
- (UL)-C(UL) Listed
- Meets TIA/EIA 568B.2 Category 5e Specifications
- Flame Rating: UL1666
| 4245 Control Cable | Specifications |
| Pairs | 4 (8 Conductors) |
| Conductor Type | 24 AWG Solid |
| Nominal D.C.R. | 26 Ohms/Mft |
| Insulation | Polyolefin |
| Shielding & Coverage | None - UTP |
| Jacket & Thickness | PVC |
| Nominal O.D. | .191 inches |
| NEC Type | CMR |
| Nom. Capacitance | Imp. | 14 pf/ft* | 100 Ohms |
| Color(s) | GY,BL,WH,BK,GN,OR,YE,PK |
Data Sheet(s) & Comparable Product(s)
Compare to Belden 1583R, Liberty 24-4P-L5-EN, Gepco/Isotec 244CAT5, Coleman/Signal 96263, COVID CAT08005E.
The broadcast audio experts at 3D HD Gear can help you find the best Category 5e cable to suit all of your studio wiring needs
West Penn Wire 4245 CAT5E Intercom Cable is available for purchase in 500 ft. & 1000 ft. spools, brought to you by
West Penn Wire professional cables are engineered to exceed the capacitance, impedance, and frequency response for broadcast system requirements, and are constructed of superior, high-end compounds for low capacitance and flat frequencies.
