West Penn Wire 4246 23 AWG CAT6 UTP Cable 1000FT (5 colors)
West Penn Wire 4246 Category 6 Network Cable, non-plenum, featuring 23 AWG Solid bare copper conductors, 4 Pair, Polyolefin insulation, and unshielded with overall PVC jacket.
West Penn Wire 4246 23 AWG CAT6 UTP Cable 1000FT (5 colors)
| Applications |
Indoor for:
- Category 5E Applications
- Ethernet
- IP Cameras
- Digital Integration
- And more....
| Ratings |
- NEC Type CMR
- (UL)-C(UL) Listed
- Meets or exceeds TIA/EIA 568B.2 Category 6 Specifications
- Flame Rating: UL1666
| 4246 Control Cable | Specifications |
| Pairs | 4 (8 Conductors) |
| Conductor Type | 23 AWG Solid |
| Nominal D.C.R. | 24 Ohms/Mft |
| Insulation | Polyolefin |
| Shielding & Coverage | None - UTP |
| Jacket & Thickness | PVC |
| Nominal O.D. | .220 inches |
| NEC Type | CMR |
| Nom. Capacitance | Imp. | 14 pf/ft* | 100 Ohms |
| Color(s) | GY,BL,WH,BK,GN |
Data Sheet(s) & Comparable Product(s)
Compare to Belden 7881A, Liberty 24-4P-L6-EN, Gepco/Isotec CT604/250, Coleman/Signal 97272, COVID CAT08006.
The broadcast audio experts at 3D HD Gear can help you find the best Category 6 cable to suit all of your studio wiring needs
West Penn Wire 4246 CAT6 UTP Cable is available for purchase in 500 ft. & 1000 ft. spools, brought to you by
West Penn Wire professional cables are engineered to exceed the capacitance, impedance, and frequency response for broadcast system requirements, and are constructed of superior, high-end compounds for low capacitance and flat frequencies.
